Electromagnetic Compatibility Guidance and Manufacturer’s Declaration
9650-000820-01 Rev. B Propaq M Operator’s Guide A-13
Guidance and Manufacturer’s Declaration – Electromagnetic
(IEC 60601-1-2 Table 202)
The Propaq M unit is intended for use in the electromagnetic environment specified below. The
customer or the user of the Propaq M should assure that it is used in such an environment.
Immunity Test IEC 60601 Test Level Compliance Level Electromagnetic Environment
– Guidance
Electrostatic
Discharge (ESD)
IEC 61000-4-2 ± 6 kV contact
± 8 kV air ± 6 kV contact
± 8 kV air Floors should be wood, concrete
or ceramic tile. If floors are
covered with synthetic material,
the relative humidity should be at
least 30%.
Electrical Fast
Transient / Burst
IEC 61000-4-4 ± 2 kV for power
supply lines
± 1 kV for input/
output lines ± 2 kV for power
supply lines
± 1 kV for input/
output lines Mains power quality should be
that of a typical commercial or
hospital environment.
Surge IEC 61000-4-
5 ± 1 kV differential
mode
± 2 kV common mode ± 1 kV differential
mode
± 2 kV common mode Mains power quality should be
that of a typical commercial or
hospital environment.
Voltage Dips, Short
Interruptions and
Voltage Variations on
Power Supply Input
Lines IEC 61000-4-
11 <5% U
T
(>95% dip in U
T
) for
0.5 cycle
40% U
T
(60% dip in U
T
) for
5 cycles
70% U
T
(30% dip in U
T
) for
25 cycles
<5% U
T
(>95% dip in U
T
) for
5 sec
<5% U
T
(>95% dip in U
T
) for
0.5 cycle
40% U
T
(60% dip in U
T
) for
5 cycles
70% U
T
(30% dip in U
T
) for
25 cycles
<5% U
T
(>95% dip in U
T
) for
5 sec
Mains power quality should be
that of a typical commercial or
hospital environment. If the user
of the Propaq M unit requires
continued operation during
power mains interruptions, it is
recommended that the Propaq M
unit be powered from an
uninterruptible power supply or a
battery.
Power Frequency
(50/60 Hz) Magnetic
Field IEC 61000-4-8 3 A/m 3 A/m Power frequency magnetic fields
should be at levels characteristic
of a typical location in a typical
commercial or hospital
environment.
Note: U
T
is the AC mains voltage prior to application of the test level.
