ZOLL Propaq M Rev B User Manual
Page 120
C
HAPTER
10 P
ULSE
CO-O
XIMETRY
(S
P
O2, SPCO,
AND
S
P
M
ET
)
10-6
www.zoll.com
9650-000820-01 Rev. B
Figure 10-1 Plug the Sensor Connectors Together
5.
Lower the clear plastic cover over the connection to secure it:
Figure 10-2 Lower Plastic Cover Over Cable Connection
6.
See “Connecting the SpO2 Sensor” on page 10-8 to connect the cable to the unit.
Sensor Cable Connector
Connector
Clear Protective
Cover
