C HAPTER 13 12-L EAD ECG I NTERPRETIVE A NALYSIS
13-12 www.zoll.com 9650-000820-01 Rev. B
12-Lead Display Options
The Propaq M unit provides display options that you can specify through the Supervisor
parameter control panels (access to Supervisor is passcode-controlled).
Press the Setup quick access key ( ), then select Supervisor . Using the navigation keys,
select the four digits in the Supervisor passcode. Press SAVE when you are finished. Once you
have entered your supervisor passcode, you will be able to access the display options in the
Supervisor menu.
Select the Supervisor> ECG> 12-Lead option to display the 12-Lead parameter control panel:
Specifying the 12-Lead Frequency Response
This option allows you to specify the frequency response of the 12-lead waveform display.
You can specify the following trace display ranges:
Note: The display and the recording present the waveform according to the filter setting
(Diagnostic or Filtered Diagnostic), but the 12-Lead Interpretive Analysis is always
performed using a diagnostic bandwidth that follows the unit’s AC Mains filter setting.
Enabling 12-Lead Analysis
This option allows you to enable or disable 12 Lead Analysis. The default is enabled ( On ).
Setup > Supervisor > ECG > 12-Lead ECG
Filtered Diagnostic 12-Ld Frequency Response
Display Type Frequency Response
Diagnostic 0.525 to 150 Hz
Filtered Diagnostic 0.525 to 40 Hz
