C HAPTER 14 P ATIENT D ATA
14–2 www.zoll.com 9650-000820-01 Rev. B
Note: The Propaq M unit retains stored cases even if you turn off or remove the auxiliary
power adapter.
Log Capacity Indicator
The Log quick access key has an indicator bar which shows an approximation of the current
level of data storage in the log.
When data storage reaches its capacity, the unit performs automatic log management by
deleting the oldest full disclosure case. If the log is not cleared or transferred, the Propaq M unit
continues to delete cases as needed to acquire storage capacity. For more information on
clearing or transferring the log, see page 14-3.
Capturing a Data Snapshot
Press the Snapshot button ( ) on the front panel to capture a 24-second period of numeric and
waveform patient data. The unit captures 12 seconds proceeding and 12 seconds following the
button press.
The Propaq M unit can store a minimum of 32 snapshots, including
• Monitor snapshots
• Treatment snapshots
• Alarm snapshots
Reviewing snapshots
You can perform this procedure from any main display screen.
1. Press the Home/Display button ( ) repeatedly until the Trends window displays.
2. Use the navigation keys to get to the Trends window.
3. Press the Select button to scroll through the list of trends.
Note: The snapshots have a snapshot icon next to the time stamp.
4. Select the desired snapshot from the Trends list and press Select. The snapshot numeric data
displays.
Treatment Summary Report
The Treatment Summary Report is a report that shows all of the treatment events related to a
patient such as alarm events treatment snapshots.
LOG
LOG
Indicator bar
The log is full.
The log is empty.
TREATMENT SUMARY REPORT
Name: Phillip Davies
06:06:14 New Case ID
ID: Patient 0015 Patient Mode: Adult 06:06:14 System On
