31
Merlin Mobile User’s Manual CATC SW Version 2.0
• above - 40 dBm
The valid range for a signal is between -60 and - 40 dBm
Search Status
The rightmost segment displays the current search direction: Fwd (forward)
or Bwd (backward).
Zoom In
Zoom In increases the size of the displayed elements, allowing fewer (but
larger) packet fields per screen.
• Click on the Tool Bar.
Zoom Out
Zoom Out decreases the size of the displayed elements, allowing more (but
smaller) packet fields per screen.
• Click on the Tool Bar.
3.4 Tool Tips
Throughout the application, tool tips provide useful information.
To display a tool tip, position the mouse pointer over an item. The tool tip
displays in a short moment if present. Tool tips can also be found over the
Tool Bar and in areas of the packet view screen.
3.5 Merlin Analyzer Keyboard Shortcuts
Several frequently-used operations are bound to keyboard shortcuts.
Table 2: Keyboard Shortcuts
Key Combination Operation Key Combination Operation
Ctrl+O Open file Ctrl+P Print...
Ctrl+Home Jump to First packet Ctrl+End Jump to Last packet
Ctrl+F Search Forward Ctrl+B Search Backward
F3 Find Next Ctrl+L Search for Loss of Sync
Shift+I Goto ID packet Shift+R Goto Freq Hop packet
Shift+P Goto Poll packet Shift+N Goto Null packet
Shift+M Goto DM1 packet Shift+F Goto FHS packet
Shift+1 Goto HV1 packet Shift+H Goto DH1 packet
Shift+3 Goto HV3 packet Shift+2 Goto HV2 packet
Shift+A Goto AUX1 packet Shift+V Goto DV packet
Shift+5 Goto DH3 packet Shift+4 Goto DM3 packet
