• IP (Display IP)

• TCP (Display TCP)

• UDP (Display UDP)

For example, to display LMP messages, click

.

Note

Once a decode has been performed, it will probably be necessary to scroll through
the display to find the decoded messages or protocols. You can shorten your
search by first clicking the Hide Unassociated Traffic button

.

Decoding Via the Display Options Dialog Box

The Display Options dialog box has three options for issuing decode
commands. To issue a command,

Step 1

From the menu bar, select Setup>Decoding Options

Step 2

Select the option for the desired level of decoding.

Step 3

Click OK or Apply.
