26
Merlin Mobile User’s Manual CATC SW Version 2.0
3.2 Toolbar
The Tool Bar provides access to the most popular program functions. Tool tips
describe icon functionality as the mouse arrow is moved over the icon/item.
Help
Online Help Displays Help topic associated with current Merlin window.
Help Topics... Displays online help.
Update License... Opens a dialog box for entering license key information for the
analyzer.
Display License
Information... Displays current license information for the analyzer.
About Merlin... Displays version information about Merlin.
Open file View/Hide L2CAP Message Level
Save As View/Hide SDP Message Protocol Level
Preview View/Hide SDP Transaction Protocol Level
Print… View/Hide TCS Protocol Level
Setup Record Options View/Hide RFCOMM Protocol Level
Start
Recording - presents options
for recording piconet,
inquiry, or IUT:HCI traffic
View/Hide OBEX Protocol Level
Stop Recording View AT Commands Protocol Level
Execute manual trigger.
Causes analyzer to trigger
end of recording.
View/Hide HDLC Protocol
Start Recording Wizard
View/Hide PPP
