WaveAce Remote Control
CURSOR - PARAMETER_CUSTOM, PACU
The PArameter_CUstom command controls the placement of custom cursors and can also be used to
assign any parameter for histogramming.
The command allows you to specify on which line (1 to 5) of the parameter table the cursor value will
appear when viewed on the WaveAce display.
NOTE: Use PAVA? to read the value of parameters that were set up with PACU.
Command Syntax
Parameter_Custom ,,
Where:
:= 1 to 5
:=
parameter from the table below or returned with the PAVA? query
:= {C1,C2,C3,C4,C1-C2,C1-C3,C1-C4,C2-C3,C2-C4,C3-C4,TA,TB,TC,TD}
NOTE: Multi-source expressions (e.g., C1-C2) used only with delay measurements PHASE, FRR, FRF, FFR, FFF,
LRR, LRF, LFR, and LFF.
Parameters
Parameter Definition
AMPL V Amplitude
BASE V Base
CRMS Root mean squared (current)
CMEAN V Average
DUTY + Duty cycle
FALL Fall time 90% to 10%
FFF Time between first falling edge of Source 1 and falling edge of Source 2
FFR Time between first falling edge of Source 1 and rising edge of Source 2
FPRE Falling edge preshoot
FREQ Frequency
FRF Time between first rising edge of Source 1 and falling edge of Source 2
FRR Time between first rising edge of Source 1 and rising edge of Source 2
LFF Time between last falling edge of Source 1 and falling edge of Source 2
LFR Time between last falling edge of Source 1 and rising edge of Source 2
LRF Time between last rising edge of Source 1 and falling edge of Source 2
LRR Time between last rising edge of Source 1 and rising edge of Source 2
38 920836 Rev B
