WaveAce Remote Control
Commands and Queries by Subsystem
Acquisition - Controlling Waveform Captures
Short Form Long Form What the Command/Query Does
*TRG *TRG Executes an ARM command.
ACQW ACQUIRE_WAY Specifies the acquisition mode.
ARM ARM_ACQUISITION Changes acquisition state from stopped to single.
ASET AUTO_SETUP Adjusts vertical, timebase and trigger parameters.
ATTN ATTENUATION
Selects the vertical attenuation factor of the probe.
BWL BANDWIDTH_LIMIT Enables/disables bandwidth-limiting low-pass filter.
CPL COUPLING Selects the specified input channel's coupling mode.
FRTR FORCE_TRIGGER Forces the instrument to make one acquisition.
ILVD INTERLEAVED Enables/disables Random Interleaved Sampling (RIS).
OFST OFFSET
Allows output channel vertical offset adjustment.
PDET PEAK_DETECT Enables or disables built-in peak detection function.
STOP STOP Immediately stops signal acquisition.
TDIV TIME_DIV Modifies the timebase setting.
TRCP TRIG_COUPLING
Sets the coupling mode of the specified trigger source.
TRDL TRIG_DELAY
Sets the time at which the trigger is to occur.
TRLV TRIG_LEVEL Adjusts the trigger level of the specified trigger source.
TRMD TRIG_MODE Specifies the trigger mode.
TRSE TRIG_SELECT Selects the condition that will trigger acquisition.
TRSL TRIG_SLOPE
Sets the trigger slope of the specified trigger source.
VDIV VOLT_DIV Sets the vertical sensitivity.
WAIT WAIT Prevents new analysis until current is completed.
Cursor - Performing Measurements
Short Form Long Form What the Command/Query Does
CRMS CURSOR_MEASURE
Specifies the type of cursor/parameter measurement.
CRST CURSOR_SET Allows positioning of any cursor.
CRVA? CURSOR_VALUE? Returns trace values measured by specified cursors.
PACU PARAMETER_CUSTOM
Controls parameters with customizable qualifiers.
PAVA? PARAMETER_VALUE?
Returns current parameter, mask test values.
12 920836 Rev B
