LevelOne GSW-4876 User Manual
Page 43
C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 43 –
Group
Information
Displays active MLD groups
IPv6 SFM
Information
Displays MLD Source-Filtered Multicast information including
group, filtering mode (include or exclude), source address,
and type (allow or deny)
LLDP
Link Layer Discovery Protocol
Neighbors
Displays LLDP information about a remote device connected
to a port on this switch
LLDP-MED
Neighbors
3
Displays information about a remote device connected to a
port on this switch which is advertising LLDP-MED TLVs,
including network connectivity device, endpoint device,
capabilities, application type, and policy
EEE
Displays Energy Efficient Ethernet information advertised
through LLDP messages
Port Statistics
Displays statistics for all connected remote devices, and
statistics for LLDP protocol packets crossing each port
MAC Table
Displays dynamic and static address entries associated with
the CPU and each port
VLANs
Virtual LANs
VLAN Membership Shows the current port members for all VLANs configured by
a selected software module
VLAN Port
Shows the VLAN attributes of port members for all VLANs
configured by a selected software module which uses VLAN
management, including PVID, VLAN aware, ingress filtering,
frame type, egress filtering, and PVID
VCL
VLAN Control List
MAC-based VLAN
Displays MAC address to VLAN map entries
sFlow
Displays information on sampled traffic, including the owner,
receiver address, remaining sampling time, and statistics for
UDP control packets and sampled traffic
Diagnostics
Ping
Tests specified path using IPv4 ping
Ping6
Tests specified path using IPv6 ping
VeriPHY
Performs cable diagnostics for all ports or selected port to
diagnose any cable faults (short, open etc.) and report the
cable length
Maintenance
Restart Device
Restarts the switch
Factory Defaults
Restores factory default settings
Software
Upload
Updates software on the switch with a file specified on the
management station
Image Select
Displays information about the active and alternate (backup)
firmware images in the switch, and allows you to revert to
the alternate image
Table 4: Main Menu (Continued)
Menu
Description
Page
