IPv6 – IPv6 frame type includes the same settings as those used

for IPv4, except for the Source IP. When configuring a specific IPv6

source address, enter the least significant 32 bits (a.b.c.d) using

the same type of mask as that used for an IPv4 address.

■

Sport – Source TCP/UDP port. (Any, Specific/Range: 0-65535)

■

Dport – Destination TCP/UDP port. (Any,

Specific/Range: 0-65535)

Action Parameters
Indicates the classification action taken on ingress frame if the configured

parameters are matched in the frame's content. If a frame matches the
QCE, the following actions will be taken:

◆

Class (Classified QoS Class) – If a frame matches the QCE, it will be

put in the queue corresponding to the specified QoS class, or placed in

a queue based on basic classification rules. (Options: 0-7, Default (use

basic classification); Default setting: 0)

◆

DPL – The drop precedence level will be set to the specified value or

left unchanged. (Options: 0-1, Default; Default setting: Default)

◆

DSCP – The DSCP value will be set to the specified value or left

unchanged. (Options: 0-63, BE, CS1-CS7, Default (not changed);

Default setting: Default)

NTERFACE

To configure QoS Control Lists:

Click Advanced Configuration, QoS, QoS Control List.

Click the

button to add a new QCE, or use the other QCE

modification buttons to specify the editing action (i.e., edit, delete, or

moving the relative position of entry in the list).

When editing an entry on the QCE Configuration page, specify the
relevant criteria to be matched, and the response to a match.

Click Save.
