C HAPTER 4 | Configuring the Switch
IGMP Snooping
– 144 –
◆ Start Address - The starting IPv4/IPv6 Multicast Group Address that
will be used as a streaming channel.
◆ End Address - The ending IPv4/IPv6 Multicast Group Address that will
be used as a streaming channel.
◆ Channel Name – An optional attribute used to indicate the name of an
channel (or multicast group) assigned to an MVR VLAN. (Range: 1-32
alphanumeric characters, containing at least one alphabetic character)
W EB I NTERFACE
To display or configure MVR channel settings:
1. Click Advanced Configuration, MVR.
2. Click the edit symbol for a channel, opening the MVR Channel
Configuration page.
3.
Enter the IP range for a multicast group, and the channel name as
required.
4. Click Save.
Figure 54: Configuring MVR Channel Settings
IGMP S NOOPING
Multicasting is used to support real-time applications such as
videoconferencing or streaming audio. A multicast server does not have to
establish a separate connection with each client. It merely broadcasts its
service to the network, and any hosts that want to receive the multicast
register with their local multicast switch/router. Although this approach
reduces the network overhead required by a multicast server, the
broadcast traffic must be carefully pruned at every multicast switch/router
it passes through to ensure that traffic is only passed on to the hosts which
subscribed to this service.
This switch can use Internet Group Management Protocol (IGMP) to filter
multicast traffic. IGMP Snooping can be used to passively monitor or
“snoop” on exchanges between attached hosts and an IGMP-enabled
device, most commonly a multicast router. In this way, the switch can
