28
Another way to close a window is to uncheck a box in the Toolbars menu.
To move a toolbar:
Click on the double line on the left side of a toolbar and drag it to the position you want.
To hide or display a toolbar
Go to the View menu, point to Toolbars, and then uncheck or check the toolbar you want to hide or show. And if user drag
to as an individual menu in window, simply click the button on the top right corner of the menu to close it.
To change the look of the CMS Client to a preset style:
In the View menu, point to Application Look, and choose one of the following preset application looks: Office 2000 / Office
XP / Office 2003 / Visual Studio.NET 2005 / Windows XP / Office 2007
System Operate Mode/Edit Mode
To carry out most administrator functions, you need to be in Edit Mode.
Press the Edit Mode toggle button to enter Edit Mode, and press it again to exit Edit Mode. When in Edit
Mode, the CMS Client will not receive alarms. A flashing indicator reminds you that you are in Edit Mode.
Any changes made to the system must be saved with the Commit button. When administrators
click the Commit button to save changes, other users will be disconnected from the CMS server and will
need to log in again.
CMS Matrix Window Introduction
Move Mouse to right-down area, the icon would auto appear. User can edit/exit the Matrix, further option
please see page 54.
SQL Server Introduction
CMS system is use SQL Server 2005 Express of Microsoft free application software as database. recommend user to use
Microsoft SQL Server Management Studio Express to backup SQL Server. Please refer the web site of Microsoft
http://technet.microsoft.com/en-us/library/ms365247.aspx .
