Cylinder control valve installation, Figure 5, Figure 4 – Alamo DSEB-D16 User Manual
Page 80
© 2003
Alamo Group Inc.
A-Boom (JD 6615 / 7615 Asy Instruction Manual) 07/03
Section 8 - 9
Cylinder Control Valve Installation
3.
Turn the Jam Nut and the Flange/
Sleeve Assembly onto the threaded cable
end to the entire length of the threads.
Cables are not included in Valve connec-
tion Kit. (See Figure 5).
Figure 5
Flange Sleeve
Flange
Flange Bolts
Flat Washers
Lock Washers
Connecting Pin
Retaining Pin
Spacer Rings
Cable (Valve End Shown - Not
included with Connection Kit)
Figure 4
Cable Eye Fitting
Cable Eye Jam Nut
