© 2003 Alamo Group Inc. Section1 - 3
A-Boom (JD 6615 / 7615 Asy Instruction Manual) 07/03
A-BOOM PRE-DELIVERY INSPECTION CHECKLIST
Pre-Operation Inspection: After Assembly is complete. Check the following items
before operating the unit to assure that they are properly assembled. (See following page 1-4
for component location)
Saftey Equipment:
----- Operators Manual is with Unit.
----- The Safety Decals are installed as listed in the Assembly Manual.
----- Valve operation plate is installed.
----- Operators cage or Tractor Cab is in place. (Item 1 page 1-5)
----- Deflectors are installed on the Mower Head. (Item 2 page 1-5)
----- Tractor Rops or Cab with seatbels installed properly.
Frame and Boom:
----- Axle Plate Bolts are torqued to 240 ft. lbs. (Item 3 page 1-5)
----- Boom Rest Axle Plate Bolts are torqued to 240 ft. lbs.
----- Front Rail Bolts are torqued to 170 ft. lbs. (Item 17 page 1-5)
----- Front Support Bolts are torqued to 240 ft. lbs. (Item 4 page 1-5)
----- Hydraulic Tank mounting Pins / Bolts in place correctly.
----- Boom Main Pins are torqued to 170 ft. lbs.
----- King Pin Retaining Nut is properly locked in place.
----- All Welds inspected toinsure proper welds and locations.
Hydraulic System:
----- Oil Level in Hydraulic Tank is within the sight gauge. (Item 5 page 1-5)
----- Hose connections are tightented according to specifications.
----- Hoses do not have any kinks or twist in them.
----- Front Pump Shaft adapter bolts are tight. (Item 6 page 1-5)
----- Front Pump Shaft Coupler / Drive Shaft is lubricated and has an anti-seize compound
on the Splines of Pump and Shafts. (Item 7 page 1-5)
----- The Pump Drive Shaft has correct alignment.
----- Suction Hose has no leaks or kinks.
Rotary Mower Head:
----- Skid Shoe Bolts are torqued to 120 ft. lbs. (Item 8 page 1-5)
----- Spindle Housing Bolts are torqued to 400 ft. lbs. (Item 9 page 1-5)
----- The Spindle Housing is properly lubricated. (item 10 page 1-5)
----- Motor Bolts are torqued to 120 ft. lbs. (Item 11 page 1-5)
----- Blade Carrier (Bar) Bolts torque to 400 ft. lbs. (Item 12 page 1-5)
----- All Blade Bolts are torqued, the retainings Pins are in place. (item 13 page 1-5)
----- Blades Swing freely. (Item 14 page 1-5)
