Alamo DSEB-D16 - Manual (Page 4)

A-Boom (JD 6615 / 7615 Asy Instruction Manual) 07/03
© 2003 Alamo Group Inc.
Index -4
Page
Safety Section
Operation Safety............................................................................. 1
Section 1
Tools and Supplies Needed f/ Assembly.................................. 1-2
Pre-Dilivery Check List...................................................................... 1-3 to 1-5
Section 2
Fill Left rear Wheel w/ calcium Cloride............................................. 2-2
Wheel Counter Weight Parts.............................................................2-2
Wheel Counter Weight Installation.................................................... 2-3
Section 3
Front Pump Drive Parts..................................................................... 3-2
Crankshaft Pulley Preparation........................................................... 3-3
Pump Driveshaft Assembly............................................................... 3-3
Pump Driveshaft Half, Shaft End....................................................... 3-4
Pump Mount Plate..............................................................................3-4 to 3-5
Pump Drive Shaft, Tube End............................................................. 3-5
Pump Installation................................................................................3-5 to 3-6
Frame Rail Support Installation......................................................... 3-7
Section 4
Frame Rail Pre- Assembly................................................................ 4-2 to 4-6
High Frame Parts...............................................................................4-7
Frame Rail Pre-Installation................................................................ 4-8 to 4-11
High Frame Pre-Installation............................................................... 4-12 to 4-16
Tack Welding Frame Assembly........................................................ 4-17 to 4-21
Remove Frame for Final Welding......................................................4-21 to 4-23
Section 5
Frame Rails Final Installation.............................................................5-2
Boom Rest Installation....................................................................... 5-3
Axle Strap Installation......................................................................... 5-4
Stabilizer Kit Installation..................................................................... 5-4
High Frame Installation...................................................................... 5-5 to 5-8
Tie Up Hoses to Tractor Frame (Stack valve Hoses)....................... 5-8
Section 6
Hydraulic Tank Installation................................................................. 6-2
Hydraulic Tank Counter Weight Installation...................................... 6-2
Hydraulic Tank Oil Level Sight Gauge............................................... 6-3
Hydraulic Tank Decal Installation....................................................... 6-3
Cab Decal Installation........................................................................ 6-4
INDEX - ASSEMBLY INSTRUCTION
