8. Installation
63
8.3.4 Installation from Rear Side
When installing the actuator from the rear side, provide a rear mounting plate of a slightly-projected
circular column shape as shown below, to facilitate the positioning.
φ16
1.5
A
Rear mounting plate
RP3NA, RP3N
(Lead screw, ball screw)
RP4NA, RP4N
(Lead screw, ball screw)
-0.2 -0.2
A I 25
-0.3
I 30
-0.3
