6. Specifications
29
Stroke [mm]
Model
Motor Type
Lead [mm]
25
30
50
75
100
2
-
100
-
-
-
4
-
200
-
-
-
GD4N
(Lead screw)
20W
6
-
220
-
-
-
2
-
100
-
-
-
4
-
200
-
-
-
GD4N
(Ball screw)
20W
6
-
270<220>
-
-
-
1
50
-
50
-
-
2
100
-
100
-
-
SD3NA
SD3N
(Lead screw)
10W
4
200
-
200
-
-
1
50
-
50
-
-
2
100
-
100
-
-
SD3NA
SD3N
(Ball screw)
10W
4
200
-
200
-
-
2
100
-
100
100
-
4
200
-
200
200
-
SD4NA
SD4N
(Lead screw)
20W
6
200
-
300
300
-
2
100
-
100
100
-
4
200
-
200
200
-
SD4NA
SD4N
(Ball screw)
20W
6
240<200>
-
300
300
-
(Note) The maximum speed may not be reached depending on the acceleration/deceleration setting.
Values in < > are for when mounted vertically.
Caution : Do not set a speed or acceleration/deceleration exceeding the applicable rating.
Doing so may result in vibration, failure or shorter life.
Setting the acceleration/deceleration exceeding the applicable rating may also cause
creep.
