1. Part Names
11
1. Part Names
The names of the actuator parts are indicated below.
In this manual, the right and left are determined by viewing the actuator from the top and from the
motor side.
1.1 Slim Types
RA2AC (Motor coupling types), RA2AR (Motor reversing types)
Ɣ RA2AC
Opposite side
of the motor
Motor side
Right side
Left side
Motor Actuator cable
Motor bracket
Rod
Rod tip bracket
Bare housing
Body
Front bracket
* Refer to 2, “External Dimensions” for details.
Ɣ RA2AR
Opposite side
of the motor
Motor side
Right side
Left side
Motor
Actuator cable
Reversing bracket
Rod
Rod tip bracket
Bare housing Body
Front bracket
Pulley cover
* Refer to 2, “External Dimensions” for details.
