4. Options
24
4. Options
4.1
Connector Cable Exit Direction Changed
The standard specification is to take out the cable from the opposite side of the rod and guide
bracket. On all models other than the slide unit types SD3N and SD4N, however, you can specify
an option (Model : K2) to reverse the cable take-out direction if you wish to take out the cable from
the rod/guide bracket side due to the layout of the system, etc.
4.2
Low Power Consumption Type
This type of actuator decreases the maximum current consumption of the controller compared with
the standard actuator.
For the details, refer to the power capacity described in the catalog or the instruction manuals of
ACON/ASEL/ASEP/AMEC Controllers. The applicable model number for this option is “LA”.
Model Name
Standard specification /
High acceleration/deceleration
specification
Maximum load current
Energy-saving measure
Maximum load current
RN3NA, RP3NA, GS3NA,
GD3NA, SD3NA, RN3N,
RP3N, GS3N, GD3N, SD3N
4.4A
2.5A
RN4NA, RP4NA, GS4NA,
GD4NA, SD4NA, RN4N,
RP4N, GS4N, GD4N, SD4N
4.4A
2.5A
