Density Gage Manual 012407 27
Loop Config Menu
This menu is used to access the primary 4-20ma loop calibration procedures. It contains the following items:
ITEM FUNCTION
PV Shows and allows the user to set the variable assigned to the primary 4-20ma current
loop
Loop test This invokes a method that performs a test on the primary 4-20ma current loop
Damping Shows and allows the user to set the damping constant for the primary 4-20ma current
loop
D/A trim This invokes a method that performs the D/A trimming of the primary 4-20ma current
loop
The PV menu allows you to select one of the following:
ITEM MEANING
D1 Density represented in units that are used locally
D2 Density represented in alternate units
Proc Temp Process temperature
Pressure Process pressure (if available)
Head Temp Head temperature (if available)
Not Assigned Blank line
Aux Loop Cfg Menu
This menu is used to access the secondary 4-20ma loop calibration procedures. It contains the following items:
ITEM FUNCTION
SV is Shows and allows the user to set the variable assigned to the SV (secondary variable)
4-20ma current loop
Aux 1 Test This invokes a method that performs a test on the secondary 4-20ma current loop
Aux 1 Trim This invokes a method that performs the D/A trimming of the secondary 4-20ma
current loop
TV is Shows and allows the user to set the variable assigned to the TV (the Third Variable)
4-20ma current loop
Aux 2 Test This invokes a method that performs a test on the TV 4-20ma current loop
Aux 2 Trim This invokes a method that performs the D/A trimming of the TV 4-20ma current loop
