Density Gage Manual 012407 23
HART Output Menu
The HART Output menu is used to define the type of HART Output desired.
ITEM FUNCTION
X96S-2005 Selecting this will assign the HART card
Serial Port 1 Selecting this will allow the user to use Serial Port 1
None No HART Output desired
Com1 Protocol Menu
Com1 Protocol contains the following items:
ITEM MEANING
HART HART protocol
Ronan Setup Ronan Setup protocol
HART Menu
The Hardware menu is used to provide information about the HART interface. It contains the following items:
ITEM FUNCTION
Tag Name Shows and allows the user to set the device tag name
MultiDrop Shows and allows the user to set the multi-drop address for a device (or 0 if the device
is not used on a multi-drop loop)
Univ Rev Shows the HART universal command revision to which this device is conferment
Spec Rev Shows the HART specification revision to which this device is conferment
System Menu
The System menu is used to provide information about the X96S. It contains the following items:
ITEM FUNCTION
Serial # Shows the device serial number
Hardware Rev Shows the device hardware revision
Software Rev Shows the device software revision
Date Shows and allows the user to set the date
Hour (0-23) Shows and allows the user to set the hour
Minute Shows and allows the user to set the minute
Password Shows and allows the user to set a password from the main display to allow access to
all menus
Date/Time Format Shows and allows the user to set the date/time format used on the status display
Date/Time Format is one of the following:
ITEM MEANING
mm/dd/yy hh:mm:ss North American date and 24 hour time
mm/dd/yyyy hh:mm:ss North American Y2K date and 24 hour time,
mm/dd/yy hh:mm:ss
am/pm
North American date and 12 hour time with am/pm indication
dd-mm-yy hh:mm:ss European date and 24 hour time,
dd-mm-yyyy hh:mm:ss European Y2K date and 24 hour time
dd/mm/yy hh:mm:ss European date and 24 hour time
dd/mm/yyyy hh:mm:ss European Y2K date and 24 hour time
