Density Gage Manual 012407 19
ITEMS MEANING
degBall degrees balling
Percent_StmQual percent steam quality
Percent Acids percent acids
% Solids Variables Menu
The % Solids Variables menu is used to configure the parameters associated with the percent of solids measurement. It
contains the following items:
ITEM FUNCTION
Carrier Shows and allows the user to set the density of the carrier
Solids Shows and allows the user to set the density of the solids
% Acids Variables Menu
The % Acids Variables menu is used to configure the parameters associated with the percent of acids measurement. It
contains the following items:
ITEM FUNCTION
Algorithm Allows the user to select the desired algorithm
Parameter A Allows the user to adjust the Parameter A value
Parameter B Allows the user to adjust the Parameter B value
Parameter C Allows the user to adjust the Parameter C value
Algorithm Menu
The Algorithm menu allows the user to select the calculation associated with the percent of acids measurement.
ITEM MEANING
Linear A (Y) + B
Log In (Y) + A
Quadratic
positive/negative
A (Y)^2 + B (Y) + C
None Not used
Proc Temp Config Menu
The Proc Temp Config menu is used to configure the parameters associated with the process temperature measurement. It
contains the following items:
ITEM FUNCTION
Temp Units Shows and allows the user to set the units to be used for process temperature
Low Range Shows and allows the user to set the temperature value to be mapped to 4ma on the
current loop output, if process temperature is selected to control that current loop.
High Range Shows and allows the user to set the temperature value to be mapped to20ma on the
current loop output, if process temperature is selected to control that current loop.
Temp Units is one of the following:
ITEM MEANING
degC degrees Celsius
degF degrees Fahrenheit
degR degrees Rankine
Kelvin degrees Kelvin
