Density Gage Manual 012407 13
Status Display Menu
The menu titled “Status Display” is used to configure the device status display. It contains the following items
ITEM FUNCTION
Analog Bar Shows the current state of the analog bar display (enabled or disabled) and allows the
user change the state.
Line 1: Shows the data to be displayed on line 1 of the status display and allows the user to
change the selection
Line 2: Shows the data to be displayed on line 2 of the status display and allows the user to
change the selection
Line 3: Shows the data to be displayed on line 3 of the status display and allows the user to
change the selection
Line 4: Shows the data to be displayed on line 4 of the status display and allows the user to
change the selection
Line 5: Shows the data to be displayed on line 5 of the status display and allows the user to
change the selection
Line 6: Shows the data to be displayed on line 6 of the status display and allows the user to
change the selection
Line 7: Shows the data to be displayed on line 7 of the status display and allows the user to
change the selection
Line 8: Shows the data to be displayed on line 8 of the status display and allows the user to
change the selection
Each line can select one of the following:
SELECTION MEANING
D1 Density represented in units that are used locally
D2 Density represented in alternate units,
Proc Temp Process temperature
Pressure Process pressure (if available)
Head Temp Head temperature (if available)
4-20 mA 4-20 mA output level
Raw Cnts Raw counts (from scintillation detector) or raw analog measurement (from ionization
detector
Filt. Cnts Filtered counts (from scintillation detector) or (from ionization detector)
Date & Time Current date and time
Diagnostic Selecting this takes the user to the Diagnostic Menu
Not Assigned Blank line
Configuration Menu
The Configuration menu is used to access area configuration menus. It contains the following items:
ITEM FUNCTION
Operation Selecting this takes the user to the Operation menu
D1 Config Selecting this takes the user to the D1 Config menu
D2 Config Selecting this takes the user to the D2 Config menu
Proc Temp Config Selecting this takes the user to the Proc Temp Config menu
Pressure Config Selecting this takes the user to the Pressure Config menu
Head Temp Config Selecting this takes the user to the Head Temp Config menu
Alarms Selecting this takes the user to the
Alarm
menu
Hardware Selecting this takes the user to the Hardware menu
HART Selecting this takes the user to the HART menu
System Selecting this takes the user to the System menu
