Density Gage Manual 012407 20
Pressure Config Menu
The Pressure Config menu is used to configure the parameters associated with the process pressure measurement. It contains
the following items:
ITEM FUNCTION
Pressure Units Shows and allows the user to set the units to be used for process pressure
Low Range Shows and allows the user to set the pressure value to be mapped to 4ma on the
current loop output, if process pressure is selected to control that current loop.
High Range Shows and allows the user to set the pressure value to be mapped to20ma on the
current loop output, if process pressure is selected to control that current loop.
Pressure Units is one of the following:
ITEM MEANING
PSI Pounds per square inch
Bar Bar
G/Sqcm Grams/square centimeter
Kg/Sqcm Kilograms/square centimeter
Pa Pascal
KPa Kilopascal
atm Atmosphere
Head Temp Config Menu
The Head Temp Config menu is used to configure the parameters associated with the detector electronics temperature
measurement. It contains the following items:
ITEM FUNCTION
Temp Units Shows and allows the user to set the units to be used for head temperature
Low Range Shows and allows the user to set the temperature value to be mapped to 4ma on the
current loop output, if head temperature is selected to control that current loop.
High Range Shows and allows the user to set the temperature value to be mapped to20ma on the
current loop output, if head temperature is selected to control that current loop.
Alarms
The
Alarms
menu is used to configure the parameters associated with the analog alarms. This applies to alarms 1-8 as well as the
4-20mA alarm.
ITEM FUNCTION
Alarm Type Shows and allows the user to set the alarm type
Setpoint Shows and allows the user to set the alarm set point
Setpoint2 Shows and allows the user to set the second alarm set point 6
Hysterisis Shows and allows the user to set the alarm hysterisis percent
Alarm Type is one of the following:
ITEM MEANING
None Alarm not yet set
Low Alarm when the source is equal to or lower than Setpoint
High Alarm when the source is equal to or higher than Setpoint
Range Alarm when the source is equal to or lower than Setpoint OR the source is equal
to or higher than Setpoint2
6 The second alarm set point is only used when the alarm type is range.
