Density Gage Manual 012407 12
Root Menu
The root menu is titled “Ronan X96S – Density”. It contains the following items:
ITEM FUNCTION
Variables Selecting this takes the user to the Variables menu
Displays Selecting this takes the user to the Displays menu
Configuration Selecting this takes the user to the Configuration menu
Digital Outputs Selecting this takes the user to the Digital Outputs menu
Digital Inputs Selecting this takes the user to the Digital Inputs menu
Calibration Selecting this takes the user to the Calibration menu
Diagnostic Selecting this takes the user to the Diagnostic menu
Variables Menu
The menu titled “Variables” contains the following items:
ITEM FUNCTION
Variable Mapping Selecting this takes the user to the Variable Mapping menu
PV Shows the current value of PV (the Primary Variable)
SV Shows the current value of SV (the Secondary Variable)
TV Shows the current value of TV (the Third Variable)
QV Shows the current value of QV (the Fourth Variable)
D1 Shows the current value of D1 (the Density Variable)
D2 Shows the current value of D2 (the Density Variable in alternate units)
Proc Temp Shows the current value of Proc Temp (the Process Temperature)
Pressure Shows the current value of Pressure (the Process Pressure)
Head Temp Shows the current value of Head Temp (the Head Temperature)
Raw Counts Shows the current Raw Counts value from the detector
Filt Counts Shows the current Filtered Counts value from the detector
Variable Mapping Menu
The “Variable Mapping” menu allows the user to select the device variable to be mapped to PV, SV, TV, and QV. It contains
the following items:
ITEM FUNCTION
PV is Shows the device variable assigned to PV and allows the user to change the selection
SV is Shows the device variable assigned to SV and allows the user to change the selection
TV is Shows the device variable assigned to TV and allows the user to change the selection
QV is Shows the device variable assigned to QV and allows the user to change the selection
Each PV, SV, TV, and QV may each select one of the following:
SELECTION MEANING
D1 Density represented in units that are used locally
D2 Density represented in alternate units
Proc Temp Process temperature
Pressure Process pressure (if available)
Head Temp Head temperature (if available)
Not Assigned Blank line
