Density Gage Manual 012407 17
ITEM FUNCTION
Pres Comp Shows the current state of the pressure compensation mechanism (enabled or disabled)
and allows the user change the state
Pressure Units Shows and allows the user to se, the pressure units used to by the pressure
compensation mechanism
A Coeff Shows and allows the user to set the “A” coefficient that relates pressure to changes in
density
Enter Pressure Shows, and allows the user to set, the process pressure at the time that the gage was
Referenced (if Auto Cap was ‘enabled’ during Referencing).
Pres Auto Cap This invokes a method that captures the process temperature automatically during gage
Referencing
Scan Time Shows the amount of time to accumulate each density sample and allows the user to
change the time value
Pressure Units is one of the following:
ITEM MEANING
PSI Pounds per square inch
Bar Bar
G/Sqcm Grams/square centimeter
Kg/Sqcm Kilograms/square centimeter
Pa Pascal
KPa Kilopascal
atm Atmosphere
D1 Config Menu
The D1 Config menu is used to configure the parameters associated with the density measurement. It contains the following
items:
ITEM FUNCTION
D1 Units Shows and allows the user to set the density units used
D1 Low Range Shows and allows the user to set the density value to be mapped to 4ma on the current
loop output, if D1 is selected to control that current loop.
D1 High Range Shows and allows the user to set the density value to be mapped to20ma on the current
loop output, if D1 is selected to control that current loop.
% Solids
Variables
Selecting this takes the user to the % Solids Variables menu
% Acids
Variables
Selecting this takes the user to the % Acids Variables menu
D1 Units is one of the following:
ITEM MEANING
SGU specific gravity
degTwad degrees twaddle
degBrix degrees brix
degBaum_hv degrees baume heavy
degBaum_lt degrees baume light
degAPI degrees API
Percent_sol_wt percent solids by weight
degBall degrees balling
percent_StmQual percent steam quality
% Acids percent acids
