Density Gage Manual 012407 6
Menus/Operation
Menu Trees
The Ronan X96S Density Gage uses a tree structured menu system.
Ronan X96S - Density
Variables Variables
Status Display
Configuration
2 Variable Mapping Variable Mapping
Digital Outputs 4 PV [value units]
Digital Inputs 4 SV [value units] PV is [var mapped to PV]
Calibration 5 TV [value units] SV is [var mapped to SV]
Diagnostic QV [value units] TV is [var mapped to TV]
D1 [value units] QV is [var mapped to TV]
D2 [value units]
Proc Temp [value units]
Pressure [value units]
Head Temp [value units]
Raw Cnts [value]
Filt Cnts [value]
Status Display
Analog Bar [enable]
Line 1: [var]
Line 2: [var]
Line 3: [var]
Line 4: [var]
Line 5: [var]
Line 6: [var]
Line 7: [var]
Line 8: [var]
Figure 3-1 – Root, Variables and Displays Menus
