Density Gage Manual 012407 26
Calibration Menu
This menu is used to view and control the calibration of the X96S Density Gage. It contains the following items:
ITEM FUNCTION
State Shows the state of the density configuration process
Ref Constants Selecting this takes the user to the Ref Constants menu
Calibrate Selecting this takes the user to the Calibrate menu
Last Ref Date Shows the date on which the gage was most recently Low Referenced.
Last Ref Time Shows the time on which the gage was most recently Low Referenced
Loop Config Selecting this takes the user to the Loop Config menu
Aux Loop Cfg Selecting this takes the user to the Aux Loop Cfg menu
State is one of the following:
ITEM MEANING
Uncalibrated Needs reference and calibrate or slope.
Referenced Needs calibrate or slope
Partial Cal Needs reference or slope
Need Ref Density Reference density must be entered
Need Cal Density Calibration density must be entered
Fully Calibrated Calibration complete
Invalid Data Reference and calibrate data is inconsistent
Ref Constants Menu
This menu is used to view and control the reference constants used in the reference and calibration procedures. It contains the
following items:
ITEM FUNCTION
Ref Mode Shows and allows the user to set the reference mode
Calib. Mode Shows and allows the user to set the Calibrate Mode
Ref Time Shows and allows the user to set the number of seconds of data to collect for a
reference or calibrate sample
MinRefCnts Shows and allows the user to set the minimum raw value to use for a reference or
calibrate sample
MaxRefCnts Shows and allows the user to set the maximum raw value to use for a reference or
calibrate sample
Ref Mode and Calib. Mode has to be selected to one of the following:
ITEM MEANING
Empty Nothing (just air) in measuring area.
Water Measuring area filled with water.
Process Process material in measuring area (density must be provided).
Absorber Absorber placed in radiation path.
