Density Gage Manual 012407 18
% Solids Variables Menu
The % Solids Variables menu is used to configure the parameters associated with the percent of solids measurement. It
contains the following items:
ITEM FUNCTION
Carrier Shows and allows the user to set the density of the carrier
Solids Shows and allows the user to set the density of the solids
% Acids Variables Menu
The % Acids Variables menu is used to configure the parameters associated with the percent of acids measurement. It
contains the following items:
ITEM FUNCTION
Algorithm Allows the user to select the desired algorithm
Parameter A Allows the user to adjust the Parameter A value
Parameter B Allows the user to adjust the Parameter B value
Parameter C Allows the user to adjust the Parameter C value
Algorithm Menu
The Algorithm menu allows the user to select the calculation associated with the percent of acids measurement.
ITEM MEANING
Linear A (Y) + B
Log In (Y) + A
Quadratic pos/neg A (Y)^2 + B (Y) + C
None Not used
D2 Config Menu
The D2 Config menu is used to configure the parameters associated with the alternate representation of the density
measurement. It contains the following items:
ITEM FUNCTION
D2 Units Shows and allows the user to set the density units used for the alternate representation
of the density measurement
D2 Low Range Shows and allows the user to set the density value to be mapped to 4ma on the current
loop output, if D2 is selected to control that current loop.
D2 High Range Shows and allows the user to set the density value to be mapped to20ma on the current
loop output, if D2 is selected to control that current loop.
% Solids
Variables
Selecting this takes the user to the % Solids Variables menu
% Acids
Variables
Selecting this takes the user to the % Acids Variables menu
D2 Units is one of the following:
ITEMS MEANING
SGU specific gravity
degTwad degrees twaddle
degBrix degrees brix
degBaum_hv degrees baume heavy
degBaum_lt degrees baume light
degAPI degrees API
Percent_sol_wt percent solids by weight
