Density Gage Manual 012407 10
Digital Outputs Output
Output [Relay 1-4/TTL 1-4] Relay 1
Select Sources [variable] Relay 2
Polarity [variable] Relay 3
Relay 4
TTL 1
TTL 2
TTL 3
TTL 4
Select Sources
Output [selected relay or TTL]
Alarm 1 [yes/no]
Alarm 2 [yes/no]
Alarm 3 [yes/no]
Alarm 4 [yes/no]
Alarm 5 [yes/no]
Alarm 6 [yes/no]
Alarm 7 [yes/no]
Alarm 8 [yes/no]
Auto Cal Ref [yes/no]
Auto Cal Err [yes/no]
Ref Prompt [yes/no]
Wipe Test [yes/no]
Shutter Test [yes/no]
Empty Clamp [yes/no]
Detector Flt [yes/no]
System Alarm [yes/no]
Polarity
No/Not Driven
NC/Driven
Open/Not Driven
Closed/Driven
Digital Inputs Input 1
Input 1 Use [not used/auto ref]
Polarity [high/low]
Figure 4-1– Digital Output and Digital Input Menus
