FEC DSP1500 Main Unit - Manual (Page 93)

enFORCE DSP1500 Main Unit Hardware Manual
PAGE 5 - 53 (Rev. 4.0)
Chapter 5: Control Interfaces
CC-Link Specifications
Speed 156K - 10M baud - selectable
Stations 64 Max.
Distance 1200m max. at 156K baud / 50m max. at 10Mbit/s
Cable Shielded Copper Twisted Pair
Mitsubishi BA1SJ61-(m) m=Meters
Belden 8102 or equivalent
Communications Type Master/Slave - EIA RS485
Transmission Format HDLC Standard
Maximum Cyclic I/O Size 896 inputs, 896 outputs max. Size set in groups of 256 I/O
(Occupied Stations)
I/O Configuration* I/O addressing set by PLC TO / FROM commands in Logic
* Actual I/O addressing must be assigned in the PLC logic. See the Mitsubishi User Manual #
13J872 Control & Communication - Link System Master / Local Module for logic reference. (Ref.
Section 10)
Configuration
Configuration of the CC-Link system is done in the PLC Logic. It is essential that this
configuration matches the Dip Switch settings of the FEC CC-Link slave. FEC is considered a
“Remote Device” in the PLC configuration. The number of “Occupied Stations” set in the PLC
must also match the settings in the DSP User Console set-up. (Note: The last 16 output
addresses are used by the CC-Link communication & cannot be used by the user)
FEC CC-Link (Version 2) I/O configuration is programmable using the DSP User Console
software. I/O can be set as required by the application according to parameter limits set forth by
the CC-Link System Profile (CSP file). The DSP Software allows configuration of the number of
Occupied Stations and Extended Cyclic Settings in the Multi Unit. Configuration of the CC-Link
Master MUST match the configuration of the FEC CC-Link slave.
CSP File
To simplify network configuration, CC-Link devices may be associated with a CC-Link System
Profile, also known as a CSP-file. This file contains a description of the device and can be used
by some CC-Link system utilities to simplify the configuration process.
The CSP file associated with the FEC device can be downloaded directly from HMS -
www.hms.se.
