enFORCE DSP1500 Main Unit Hardware Manual
(Rev. 4.0) PAGE 5 - 24
Chapter 5: Control Interfaces
DeviceNet Specifications
Speed 125K, 250K and 500K baud
Nodes 64
Maximum Distance
500 meters at 125K baud
250 meters at 250K baud
100 meters at 500K baud
Cable
Twisted pair for signal and power
Allen Bradley or equivalent ;
Thin Cable #1485C-P1-C
Thick Cable # 1485C-P1-A
Communications Type Master/Slave
Interface Board Specifications
Operating Voltage +5V, 200 ma
Output data bytes 512 max.*
Input data bytes 512 max.*
Servers per group 2 Maximum
Interface type Dual Port RAM or Serial Interface
* Typical configuration is 32 Bytes (256 I/O points) but can be altered using the DSP Software
package. (See AnyBus-S Reference at the end of this chapter for I/O Setting example.)
EDS File
Each device on a DeviceNet network is associated with an EDS file containing all necessary
information about the device to be connected. The network configuration program uses this file
during configuration of the network.
The EDS file associated with the FEC device can be downloaded from the FEC website.
www.fec-usa.com (file: abs.eds)
Direct link:www.fec-usa.com/fecusacomnew/support/index.htm
(the file can also be downloaded directly from HMS - www.hms.se)
Note: The FEC system will appear in the network Vendor list as “HMS Fieldbus Systems” and in
the network as “Anybus-S DeviceNet” adapter. This is the manufacturer of the interface board
which is integrated into the Main Unit.
