Chapter 5: Control Interfaces
CH. No. Bit Signal Connection
FEC Main
Description
Bank Bit
Input CH.
No.04
0bit BYPASS PRESS#27 NO 49 Bypass press No. 27.
1bit BYPASS PRESS#28 NO 50 Bypass press No. 28.
2bit BYPASS PRESS#29 NO 51 Bypass press No. 29.
3bit BYPASS PRESS#30 NO 52 Bypass press No. 30.
4bit BYPASS PRESS#31 NO 53 Bypass press No. 31.
5bit NO 54
6bit NO 55
7bit NO 56
8bit NO 57
9bit NO 58
10bit NO 59
11bit NO 60
12bit NO 61
13bit NO 62
14bit NO 63
15bit NO 64
The Channel Number at the Master Unit output side differs according to node address settings.
Please check before operating the unit.
