enFORCE
DSP1500 Main Unit Hardware Manual
PAGE 5 - 51
(Rev. 4.0)
Chapter 5: Control Interfaces
5.8.4 Ouput Signals
The Main Unit is capable of providing over 570 Output signals to indicate the status of the Main
Unit and of all the DSP1500 SAN Controllers connected to it (up to 31 controllers). These
signals are user configurable using the DSP User Console Software and may be programmed
on any designated bit. See Section 5.3.4 for available output signals.
Address
Signal
Connection
FEC Main
Description
Bank
Bit
Standard
Setting
RX(n+0)0
Total Reject
NO
1
1
Output when result is a [Total Reject].
RX(n+0)1
Total Accept
NO
1
2
Output when result is a [Total Accept]
RX(n+0)2
Abnormal
NO
1
3
Output when a Press abnormal occurs
RX(n+0)3
Ready
NO
1
4
Output when Press operation is ready.
RX(n+0)4
Busy
NO
1
5
Output while Press is operating.
RX(n+0)5
End
NO
1
6
Output when Press operation ends.
RX(n+0)6
Seq/Press Output 0
NO
1
7
Output confirmation of SEQUENCE
SELECT 0~4 input selections.
When in manual (Jog) operation these
bits are Output confirmation of the
Press Select 0~4 input selections.
RX(n+0)7
Seq/Press Output 1
NO
1
8
RX(n+0)8
Seq/Press Output 2
NO
1
9
RX(n+0)9
Seq/Press Output 3
NO
1
10
RX(n+0)A
Seq/Press Output 4
NO
1
11
RX(n+0)B
Press in Bypass
NO
1
12 Output when any press is in Bypass
RX(n+0)C
Press No.1 Accept
NO
1
13 Press NO.1 pressing is accepted.
RX(n+0)D
Press No.1 Reject
NO
1
14 Press NO.1 pressing is rejected.
RX(n+0)E
Press No.1 ABN.
NO
1
15 Press NO.1 is abnormal.
RX(n+0)F
Press No.1 BYP
NO
1
16 Press NO.1 is in bypass.
Example
of output
signal
setting
RX(n+1)0
Press No.2 Accept
NO
1
17 Press NO.2 pressing is accepted.
RX(n+1)1
Press No.2 Reject
NO
1
18 Press NO.2 pressing is rejected.
RX(n+1)2
Press No.2 ABN
NO
1
19 Press NO.2 is abnormal.
RX(n+1)3
Press No.2 BYP
NO
1
20 Press NO.2 is in bypass.
RX(n+1)4
Press No.3 Accept
NO
1
21 Press NO.3 pressing is accepted.
RX(n+1)5
Press No.3 Reject
NO
1
22 Press NO.3 pressing is rejected.
RX(n+1)6
Press No.3 ABN
NO
1
23 Press NO.3 is abnormal.
RX(n+1)7
Press No.3 BYP
NO
1
24 Press NO.3 is in bypass.
RX(n+1)8
Press No.4 Accept
NO
1
25 Press NO.4 pressing is accepted.
RX(n+1)9
Press No.4 Reject
NO
1
26 Press NO.4 pressing is rejected.
RX(n+1)A
Press No.4 ABN.
NO
1
27 Press NO.4 is abnormal.
RX(n+1)B
Press No.4 BYP
NO
1
28 Press NO.4 is in bypass.
RX(n+1)C
Press No.5 Accept
NO
1
29 Press NO.5 pressing is accepted.
RX(n+1)D
Press No.5 Reject
NO
1
30 Press NO.5 pressing is rejected.
RX(n+1)E
Press No.5 ABN.
NO
1
31 Press NO.5 is abnormal.
RX(n+1)F
Press No.5 BYP
NO
1
32 Press NO.5 is in bypass.
Example
of output
signal
setting
RX(n+2)0
Press No.6 Accept
NO
2
1
Press NO.6 pressing is accepted.
RX(n+2)1
Press No.6 Reject
NO
2
2
Press NO.6 pressing is rejected.
RX(n+2)2
Press No.6 ABN
NO
2
3
Press NO.6 is abnormal.
RX(n+2)3
Press No.6 BYP
NO
2
4
Press NO.6 is in bypass.
RX(n+2)4
Press No.7 Accept
NO
2
5
Press NO.7 pressing is accepted.
RX(n+2)5
Press No.7 Reject
NO
2
6
Press NO.7 pressing is rejected.
RX(n+2)6
Press No.7 ABN
NO
2
7
Press NO.7 is abnormal.
RX(n+2)7
Press No.7 BYP
NO
2
8
Press NO.7 is in bypass.
RX(n+2)8
Press No.8 Accept
NO
2
9
Press NO.8 pressing is accepted.
RX(n+2)9
Press No.8 Reject
NO
2
10 Press NO.8 pressing is rejected.
RX(n+2)A
Press No.8 ABN.
NO
2
11 Press NO.8 is abnormal.
RX(n+2)B
Press No.8 BYP
NO
2
12 Press NO.8 is in bypass.
RX(n+2)C
Press No.9 Accept
NO
2
13 Press NO.9 pressing is accepted.
RX(n+2)D
Press No.9 Reject
NO
2
14 Press NO.9 pressing is rejected.
RX(n+2)E
Press No.9 ABN.
NO
2
15 Press NO.9 is abnormal.
RX(n+2)F
Press No.9 BYP
NO
2
16 Press NO.9 is in bypass.
：
Bit
Signal
Connection
Description
For
CC-Link
Comm.
Only
RX(n+7)0 Unusable
NO
The last 16 bits are reserved for CC-Link
Communication only regardless of how many
stations are set.
… …
…
RX(n+7)F Unusable
NO
