enFORCE
DSP1500 Main Unit Hardware Manual
(Rev. 4.0)
PAGE 5 - 64
Chapter 5: Control Interfaces
5.10.3 Input Signals (CH1 ~ CH16)
Inputs are assigned in the order as shown in the table below and cannot be changed. Bits
designated as “Unused” have no input assigned to them.
CH. No.
Bit
Signal
Connection
FEC Main
Description
Bank
Bit
Input CH.
No.01
0bit
Emergency Stop
NC
1
Stop Press operation.
1bit
Reset
NO
2
Reset and return to initial status
2bit
Return
NO
3
Press jog return operation.
3bit Start
NO
4
Start Press pressing.
In Jog operation, Jog+Start
advances the press
4bit Home
NO
5 Home
Search / Return Home
5bit Jog
NO
6
Manual Mode operation
Jog+Start advances the press
Jog+Return returns the press
6bit
Seq. / Press Sel. 0
NO
7
Select sequence / press.
Select the sequence No. 1 ~32 at
Sequence Select 0 ~4.
In Jog operation these are the
press selection bits.
7bit
Seq. / Press Sel. 1
NO
8
8bit
Seq. / Press Sel. 2
NO
9
9bit
Seq. / Press Sel. 3
NO
10
10bit
Seq. / Press Sel. 4
NO
11
11bit Unused
NO
12
12bit
INPORT 1
NO
13
Input for Sequence “INPORT 1”.
13bit
INPORT 2
NO
14
Input for Sequence “INPORT 2”.
14bit
INPORT 3
NO
15
Input for Sequence “INPORT 3”.
15bit
INPORT 4
NO
16
Input for Sequence “INPORT 4”.
CH. No.
Bit
Signal
Connection
FEC Main
Description
Bank
Bit
Input CH.
No.02
0bit
BYPASS PRESS#1
NO
17
Bypass press No. 1.
1bit
BYPASS PRESS#2
NO
18
Bypass press No. 2.
2bit
BYPASS PRESS#3
NO
19
Bypass press No. 3.
3bit
BYPASS PRESS#4
NO
20
Bypass press No. 4.
4bit
BYPASS PRESS#5
NO
21
Bypass press No. 5.
5bit
BYPASS PRESS#6
NO
22
Bypass press No. 6.
6bit
BYPASS PRESS#7
NO
23
Bypass press No. 7.
7bit
BYPASS PRESS#8
NO
24
Bypass press No. 8.
8bit
BYPASS PRESS#9
NO
25
Bypass press No. 9.
9bit
BYPASS PRESS#10
NO
26
Bypass press No. 10.
10bit Unused
NO
27
11bit Unused
NO
28
12bit Unused
NO
29
13bit Unused
NO
30
14bit Unused
NO
31
15bit Unused
NO
32
CH. No.
Bit
Signal
Connection
FEC Main
Description
Bank
Bit
Input CH.
No.03
0bit
BYPASS PRESS#11
NO
33
Bypass press No. 11.
1bit
BYPASS PRESS#12
NO
34
Bypass press No. 12.
2bit
BYPASS PRESS#13
NO
35
Bypass press No. 13.
3bit
BYPASS PRESS#14
NO
36
Bypass press No. 14.
4bit
BYPASS PRESS#15
NO
37
Bypass press No. 15.
5bit
BYPASS PRESS#16
NO
38
Bypass press No. 16.
6bit
BYPASS PRESS#17
NO
39
Bypass press No. 17.
7bit
BYPASS PRESS#18
NO
40
Bypass press No. 18.
8bit
BYPASS PRESS#19
NO
41
Bypass press No. 19.
9bit
BYPASS PRESS#20
NO
42
Bypass press No. 20.
10bit
BYPASS PRESS#21
NO
43
Bypass press No. 21.
11bit
BYPASS PRESS#22
NO
44
Bypass press No. 22.
12bit
BYPASS PRESS#23
NO
45
Bypass press No. 23.
13bit
BYPASS PRESS#24
NO
46
Bypass press No. 24.
14bit
BYPASS PRESS#25
NO
47
Bypass press No. 25.
15bit
BYPASS PRESS#26
NO
48
Bypass press No. 26.
