enFORCE DSP1500 Main Unit Hardware Manual
PAGE 5 - 13 (Rev. 4.0)
Chapter 5: Control Interfaces
Available Individual Press Unit Output Signals (cont’d.)
Load Low Reject
Output when the press result is below the acceptable Load Low Limit. This
output remains active until the START signal or RESET signal is input.
Load High Reject
Output when the press result is above the acceptable Load High Limit. This
output remains active until the START signal or RESET signal is input.
Part Check 2
Load Low Reject
Output when the press result is below the acceptable Part Check 2 Load Low
Limit. This output remains active until the START signal or RESET signal is
input.
Part Check 2
Load High Reject
Output when the press result is above the acceptable Part Check 2 Load High
Limit. This output remains active until the START signal or RESET signal is
input.
Part Check 3
Load Low Reject
Output when the press result is below the acceptable Part Check 3 Load Low
Limit. This output remains active until the START signal or RESET signal is
input.
Part Check 3
Load High Reject
Output when the press result is above the acceptable Part Check 3 Load High
Limit. This output remains active until the START signal or RESET signal is
input.
Distance Low Reject
Output when the press result is below the acceptable Distance Low Limit. This
output remains active until the START signal or RESET signal is input.
Distance High Reject
Output when the press result is above the acceptable Distance High Limit.
This output remains active until the START signal or RESET signal is input.
Interference Check
Zone Reject
Output if the Interference Check Load is exceeded before the press reaches
the Interference Check Distance. This output remains active until the START
signal or RESET signal is input.
Part Check 1
Distance Low Reject
Output when the press result is below the acceptable Part Check 1 Distance
Low Limit when the press has reached the Part 1 Check Load. This output
remains active until the START signal or RESET signal is input.
Part Check 1
Distance High Reject
Output when the press result is above the acceptable Part Check 1 Distance
High Limit when the press has reached the Part 1 Check Load. This output
remains active until the START signal or RESET signal is input.
Combination 1
Used to create “special” outputs formed by using a combination of SAN Unit
outputs in “AND / OR” logic
Combination 2
Combination 3
Combination 4
Combination 5
Combination 6
Combination 7
Combination 8
