enFORCE
DSP1500 Main Unit Hardware Manual
(Rev. 4.0)
PAGE 5 - 10
Chapter 5: Control Interfaces
24
BYPASS Press No.8
N.O.
Bypass’s press #8 - Press is ignored as if it does not exist.
25
BYPASS Press No.9
N.O.
Bypass’s press #9 - Press is ignored as if it does not exist.
26
BYPASS Press No.10
N.O.
Bypass’s press #10 - Press is ignored as if it does not exist.
27
Cycle Count Up
N.O.
Cycle Count Input.
The System cycle counter will increment each time this signal
is input if the CYCLE COUNT UP is set to PLC SIGNAL in the
Main Unit. The Cycle Count input requires a pulse of 200~500
milliseconds to increment the counter. If the CYCLE COUNT
UP is set to AUTO, the cycle counter increments automatically
at the end of every pressing cycle.
28
Cycle Count Clear
N.O.
The internal cycle counter is reset when this signal is inputted.
Resetting the counter value requires a 200~500ms pulse.
29 Not
Used
30 Data
Select
0
These 3 inputs form a binary code to select up to 8 Output
Data Banks. Used for Digital I/O interfaces. NOTE: Not used
for Fieldbus interfaces. [See Table 3 on Page 5-12]
31 Data
Select
1
N.O.
32 Data
Select
2
33 Input
Signal
Power
Common for input signal.
Sink Type
+24V
34
Input Signal Power
Source Type
+0V
Note) NC: Normal Closed, NO: Normal Open
[Table 1] Sequence / Press Selection
Seq. / Press
Select 4
Seq. / Press
Select 3
Seq. / Press
Select 2
Seq. / Press
Select 1
Seq. / Press
Select 0
Selected
Sequence
No.
Selected
Press No.
OFF OFF OFF
OFF
OFF
1
1
OFF OFF OFF OFF ON
2
2
OFF OFF OFF ON OFF 3
3
OFF OFF OFF ON
ON
4
4
OFF OFF ON OFF OFF 5
5
OFF OFF ON OFF ON
6
6
OFF OFF ON
ON OFF 7
7
OFF OFF ON
ON
ON
8
8
OFF
ON OFF OFF OFF 9
9
OFF
ON OFF
OFF
ON
10
10
OFF
ON OFF ON OFF 11
11
OFF
ON OFF ON
ON
12
12
OFF
ON
ON OFF OFF 13
13
OFF
ON
ON OFF ON
14
14
OFF
ON
ON
ON OFF 15
15
OFF
ON
ON
ON
ON
16
16
ON OFF OFF OFF OFF 17
17
ON OFF OFF OFF ON
18
18
ON OFF OFF ON OFF 19
19
ON OFF OFF ON
ON
20
20
ON OFF ON
OFF
OFF
21
21
ON OFF ON OFF ON
22
22
ON OFF ON
ON OFF 23
23
ON OFF ON
ON
ON
24
24
ON
ON OFF OFF OFF 25
25
ON
ON OFF OFF ON
26
26
ON
ON OFF ON OFF 27
27
ON
ON OFF ON
ON
28
28
ON
ON
ON OFF OFF 29
29
ON
ON
ON
OFF
ON
30
30
ON
ON
ON
ON OFF 31
31
ON
ON
ON
ON
ON
32
