enFORCE DSP1500 Main Unit Hardware Manual
PAGE 5 - 49 (Rev. 4.0)
Chapter 5: Control Interfaces
5.8.2 Input Signals
Inputs are assigned in the order as shown in the table below and cannot be changed. Bits
designated as “Unused” have no input assigned to them.
Bit Signal Connection
FEC Main
Description
Bank Bit
RY(n+0)0 Emergency Stop NC 1 Stop Press operation.
RY(n+0)1 Reset NO 2 Reset and return to initial status
RY(n+0)2 Return NO 3 Press jog return operation.
RY(n+0)3 Start NO 4
Start Press pressing.
In Jog operation, Jog+Start advances the
press
RY(n+0)4 Home NO 5 Home Search / Return Home
RY(n+0)5 Jog NO 6
Manual Mode operation
Jog+Start advances the press
Jog+Return returns the press
RY(n+0)6 Seq. / Press Sel. 0 NO 7 Select sequence / press.
Select the sequence No. 1 ~32 at
Sequence Select 0 ~4.
In Jog operation these are the press
selection bits.
RY(n+0)7 Seq. / Press Sel. 1 NO 8
RY(n+0)8 Seq. / Press Sel. 2 NO 9
RY(n+0)9 Seq. / Press Sel. 3 NO 10
RY(n+0)A Seq. / Press Sel. 4 NO 11
RY(n+0)B Unused NO 12
RY(n+0)C INPORT 1 NO 13 Input for Sequence “INPORT 1”.
RY(n+0)D INPORT 2 NO 14 Input for Sequence “INPORT 2”.
RY(n+0)E INPORT 3 NO 15 Input for Sequence “INPORT 3”.
RY(n+0)F INPORT 4 NO 16 Input for Sequence “INPORT 4”.
Bit Signal Connection
FEC Main
Description
Bank Bit
RY(n+1)0 BYPASS PRESS#1 NO 17 Bypass press No. 1.
RY(n+1)1 BYPASS PRESS#2 NO 18 Bypass press No. 2.
RY(n+1)2 BYPASS PRESS#3 NO 19 Bypass press No. 3.
RY(n+1)3 BYPASS PRESS#4 NO 20 Bypass press No. 4.
RY(n+1)4 BYPASS PRESS#5 NO 21 Bypass press No. 5.
RY(n+1)5 BYPASS PRESS#6 NO 22 Bypass press No. 6.
RY(n+1)6 BYPASS PRESS#7 NO 23 Bypass press No. 7.
RY(n+1)7 BYPASS PRESS#8 NO 24 Bypass press No. 8.
RY(n+1)8 BYPASS PRESS#9 NO 25 Bypass press No. 9.
RY(n+1)9 BYPASS PRESS#10 NO 26 Bypass press No. 10.
RY(n+1)A Unused NO 27
RY(n+1)B Unused NO 28
RY(n+1)C Unused NO 29
RY(n+1)D Unused NO 30
RY(n+1)E Unused NO 31
RY(n+1)F Unused NO 32
Bit Signal Connection
FEC Main
Description
Bank Bit
RY(n+2)0 BYPASS PRESS#11 NO 33 Bypass press No. 11.
RY(n+2)1 BYPASS PRESS#12 NO 34 Bypass press No. 12.
RY(n+2)2 BYPASS PRESS#13 NO 35 Bypass press No. 13.
RY(n+2)3 BYPASS PRESS#14 NO 36 Bypass press No. 14.
RY(n+2)4 BYPASS PRESS#15 NO 37 Bypass press No. 15.
RY(n+2)5 BYPASS PRESS#16 NO 38 Bypass press No. 16.
RY(n+2)6 BYPASS PRESS#17 NO 39 Bypass press No. 17.
RY(n+2)7 BYPASS PRESS#18 NO 40 Bypass press No. 18.
RY(n+2)8 BYPASS PRESS#19 NO 41 Bypass press No. 19.
RY(n+2)9 BYPASS PRESS#20 NO 42 Bypass press No. 20.
RY(n+2)A BYPASS PRESS#21 NO 43 Bypass press No. 21.
RY(n+2)B BYPASS PRESS#22 NO 44 Bypass press No. 22.
RY(n+2)C BYPASS PRESS#23 NO 45 Bypass press No. 23.
RY(n+2)D BYPASS PRESS#24 NO 46 Bypass press No. 24.
RY(n+2)E BYPASS PRESS#25 NO 47 Bypass press No. 25.
RY(n+2)F BYPASS PRESS#26 NO 48 Bypass press No. 26.
