Chapter 5: Control Interfaces
5.7.3 Input Signals (Word 01 ~ Word 16)
Inputs are assigned in the order as shown in the table below and cannot be changed. Bits
designated as “Unused” have no input assigned to them.
Since Modbus Plus sends I/O signals 8 bits at a time, and trying to use the data as a
word, all bits and bytes are transferred backwards.
Word No.
Bit
Signal
Connection
FEC Main
Description
Bank
Bit
Input Word
No.01
0bit
Seq. / Press Sel. 1
NO
8
Sequence / Press Select Bit 1
1bit
Seq. / Press Sel. 0
NO
7
Sequence / Press Select Bit 0
2bit Jog
NO
6
Manual Mode operation
Jog+Start advances the press
Jog+Return returns the press.
3bit Home
NO
5 Home
Search / Return Home
4bit Start
NO
4
Start Press pressing.
In Jog operation, Jog+Start
advances the press.
5bit
Return
NO
3
Press jog return operation.
6bit
Reset
NO
2
Reset and return to initial status
7bit
Emergency Stop
NC
1
Stop Press operation.
8bit
INPORT 4
NO
16
Input for Sequence “INPORT 4”.
9bit
INPORT 3
NO
15
Input for Sequence “INPORT 3”.
10bit
INPORT 2
NO
14
Input for Sequence “INPORT 2”.
11bit
INPORT 1
NO
13
Input for Sequence “INPORT 1”.
12bit Unused
NO
12
13bit
Seq. / Press Sel. 4
NO
11
Sequence / Press Select Bit 4
14bit
Seq. / Press Sel. 3
NO
10
Sequence / Press Select Bit 3
15bit
Seq. / Press Sel. 2
NO
9
Sequence / Press Select Bit 2
Word No.
Bit
Signal
Connection
FEC Main
Description
Bank
Bit
Input Word
No.02
0bit
BYPASS PRESS#8
NO
24
Bypass press No. 8.
1bit
BYPASS PRESS#7
NO
23
Bypass press No. 7.
2bit
BYPASS PRESS#6
NO
22
Bypass press No. 6.
3bit
BYPASS PRESS#5
NO
21
Bypass press No. 5.
4bit
BYPASS PRESS#4
NO
20
Bypass press No. 4.
5bit
BYPASS PRESS#3
NO
19
Bypass press No. 3.
6bit
BYPASS PRESS#2
NO
18
Bypass press No. 2.
7bit
BYPASS PRESS#1
NO
17
Bypass press No. 1.
8bit Unused
NO
32
9bit Unused
NO
31
10bit Unused
NO
30
11bit Unused
NO
29
12bit Unused
NO
28
13bit Unused
NO
27
14bit
BYPASS PRESS#10
NO
26
Bypass press No. 10.
15bit
BYPASS PRESS#9
NO
25
Bypass press No. 9.
Word No.
Bit
Signal
Connection
FEC Main
Description
Bank
Bit
Input Word
No.03
0bit
BYPASS PRESS#18
NO
40
Bypass press No. 18.
1bit
BYPASS PRESS#17
NO
39
Bypass press No. 17.
2bit
BYPASS PRESS#16
NO
38
Bypass press No. 16.
3bit
BYPASS PRESS#15
NO
37
Bypass press No. 15.
4bit
BYPASS PRESS#14
NO
36
Bypass press No. 14.
5bit
BYPASS PRESS#13
NO
35
Bypass press No. 13.
6bit
BYPASS PRESS#12
NO
34
Bypass press No. 12.
7bit
BYPASS PRESS#11
NO
33
Bypass press No. 11.
8bit
BYPASS PRESS#26
NO
48
Bypass press No. 26.
9bit
BYPASS PRESS#25
NO
47
Bypass press No. 25.
10bit
BYPASS PRESS#24
NO
46
Bypass press No. 24.
11bit
BYPASS PRESS#23
NO
45
Bypass press No. 23.
12bit
BYPASS PRESS#22
NO
44
Bypass press No. 22.
13bit
BYPASS PRESS#21
NO
43
Bypass press No. 21.
14bit
BYPASS PRESS#20
NO
42
Bypass press No. 20.
15bit
BYPASS PRESS#19
NO
41
Bypass press No. 19.
