Chapter 5: Control Interfaces
5.5.4 Ouput Signals (CH1 ~ CH16)
The Main Unit is capable of providing over 570 Output signals to indicate the status of the Main
Unit and of all the DSP1500 SAN Controllers connected to it (up to 31 controllers). These
signals are user configurable using the DSP User Console Software and may be programmed
on any designated bit. See Section 5.3.4 for available output signals.
CH. No.
Bit
Signal
Connection
FEC Main
Description
Bank
Bit
Output CH.
No.01
Standard
Setting
0bit
Total Reject
NO
1
1
Output when result is a [Total Reject].
1bit
Total Accept
NO
1
2
Output when result is a [Total Accept]
2bit
Abnormal
NO
1
3
Output when a Press abnormal occurs
3bit
Ready
NO
1
4
Output when Press operation is ready.
4bit
Busy
NO
1
5
Output while Press is operating.
5bit
End
NO
1
6
Output when Press operation ends.
6bit
Seq/Press Output 0
NO
1
7
Output confirmation of SEQUENCE
SELECT 0~4 input selections.
When in manual (Jog) operation these
bits are Output confirmation of the Press
Select 0~4 input selections.
7bit
Seq/Press Output 1
NO
1
8
8bit
Seq/Press Output 2
NO
1
9
9bit
Seq/Press Output 3
NO
1
10
10bit Seq/Press Output 4
NO
1
11
11bit Press in Bypass
NO
1
12 Output when any press is in Bypass
12bit
Press No.1 Accept
NO
1
13 Press NO.1 pressing is accepted.
13bit
Press No.1 Reject
NO
1
14 Press NO.1 pressing is rejected.
14bit
Press No.1 ABN.
NO
1
15 Press NO.1 is abnormal.
15bit
Press No.1 BYP
NO
1
16 Press NO.1 is in bypass.
Output CH.
No.02
Example of
output
signal
setting
0bit
Press No.2 Accept
NO
1
17 Press NO.2 pressing is accepted.
1bit
Press No.2 Reject
NO
1
18 Press NO.2 pressing is rejected.
2bit
Press No.2 ABN
NO
1
19 Press NO.2 is abnormal.
3bit
Press No.2 BYP
NO
1
20 Press NO.2 is in bypass.
4bit
Press No.3 Accept
NO
1
21 Press NO.3 pressing is accepted.
5bit
Press No.3 Reject
NO
1
22 Press NO.3 pressing is rejected.
6bit
Press No.3 ABN
NO
1
23 Press NO.3 is abnormal.
7bit
Press No.3 BYP
NO
1
24 Press NO.3 is in bypass.
8bit
Press No.4 Accept
NO
1
25 Press NO.4 pressing is accepted.
9bit
Press No.4 Reject
NO
1
26 Press NO.4 pressing is rejected.
10bit
Press No.4 ABN.
NO
1
27 Press NO.4 is abnormal.
11bit
Press No.4 BYP
NO
1
28 Press NO.4 is in bypass.
12bit
Press No.5 Accept
NO
1
29 Press NO.5 pressing is accepted.
13bit
Press No.5 Reject
NO
1
30 Press NO.5 pressing is rejected.
14bit
Press No.5 ABN.
NO
1
31 Press NO.5 is abnormal.
15bit
Press No.5 BYP
NO
1
32 Press NO.5 is in bypass.
Output CH.
No.03
Example of
output
signal
setting
0bit
Press No.6 Accept
NO
2
1
Press NO.6 pressing is accepted.
1bit
Press No.6 Reject
NO
2
2
Press NO.6 pressing is rejected.
2bit
Press No.6 ABN
NO
2
3
Press NO.6 is abnormal.
3bit
Press No.6 BYP
NO
2
4
Press NO.6 is in bypass.
4bit
Press No.7 Accept
NO
2
5
Press NO.7 pressing is accepted.
5bit
Press No.7 Reject
NO
2
6
Press NO.7 pressing is rejected.
6bit
Press No.7 ABN
NO
2
7
Press NO.7 is abnormal.
7bit
Press No.7 BYP
NO
2
8
Press NO.7 is in bypass.
8bit
Press No.8 Accept
NO
2
9
Press NO.8 pressing is accepted.
9bit
Press No.8 Reject
NO
2
10 Press NO.8 pressing is rejected.
10bit
Press No.8 ABN.
NO
2
11 Press NO.8 is abnormal.
11bit
Press No.8 BYP
NO
2
12 Press NO.8 is in bypass.
12bit
Press No.9 Accept
NO
2
13 Press NO.9 pressing is accepted.
13bit
Press No.9 Reject
NO
2
14 Press NO.9 pressing is rejected.
14bit
Press No.9 ABN.
NO
2
15 Press NO.9 is abnormal.
15bit
Press No.9 BYP
NO
2
16 Press NO.9 is in bypass.
：
CH. No.
Bit
Signal
Connection
Description
Output CH.
No.16
0bit NO
… …
15bit NO
The CH. No. at the Master input side differs according to node address settings.
Please check before operating the unit.
