Chapter 2: Specifications
2.1 Specifications
Power Supply Voltage 100 to 220 VAC±15%, 1-phase, 50/60 Hz.
Power Consumption 9 Watt/Hour
Operating Current Less than 70 mA
In rush current Less than 160 mA
CPU NEC V53A
Data Communication RS232C (User Console PC)
RS232C (Data Output #1)
RS232C (Data Input)
RS232C (Data Output #2)
RS422 (External Remote Display)
RS485 Servo Units Programming/Control
Ethernet - User Console (User Console PC)
Ethernet - Network Communication (2E Version Only)
Control Interfaces Discrete I/O (24Vdc Sink)
Discrete I/O (24Vdc Source)
DeviceNet
®
(includes messaging capabilities)
Interbus-S
®
Profibus
®
Mitsubishi CC Link
®
1
Allen Bradley Remote I/O
1
Modbus Plus
®
CC Link
®
Version 2 (includes messaging capabilities)
DeviceNet
®
for ToolsNet
®
Interbus-S
®
for ToolsNet
®
Profibus
®
for ToolsNet
®
Ethernet I/P (includes messaging capabilities)
M-Net
Also Available: Contact FEC for special fieldbus requirements.
Pressing Sequence
Programming Steps 100
(99 plus End Step)
Pressing
Control Methods Load Control / Distance Control
(plus 7 other special methods)
Max. No. of presses 31 per Main Unit
Pressing Parameters 32
Pressing Sequences 32
Data Storage
(non-volatile RAM)
Based on the number of
presses connected.
2
# of
Press
Stored
Cycles # of
Press
Stored
Cycles # of
Press
Stored
Cycles # of
Press
Stored
Cycles
1 8322 9 2475 17 1434 25 1012
2 6526 10 2250 18 1350 26 984
3 5289 11 2081 19 1294 27 928
4 4445 12 1941 20 1237 28 900
5 3826 13 1828 21 1181 29 872
6 3375 14 1716 22 1125 30 843
7 3010 15 1603 23 1097 31 815
8 2700 16 1519 24 1040
Installation requirement NEMA12 Enclosure
Operation Temperature 0º to 50 ºC (32 º to 122 ºF)
Operation Humidity
20% to 90%
1) Mitsubishi CC Link & Allen Bradley Remote I/O are proprietary and licensed for use.
2) The number of cycles stored will be reduced if RS232C - DATA IN data is stored with the
pressing data.
