FEC DSP1500 Main Unit - Manual (Page 90)

enFORCE DSP1500 Main Unit Hardware Manual
(Rev. 4.0) PAGE 5 - 50
Chapter 5: Control Interfaces
Bit Signal Connection
FEC Main
Description
Bank Bit
RY(n+3)0 BYPASS PRESS#27 NO 49 Bypass press No. 27.
RY(n+3)1 BYPASS PRESS#28 NO 50 Bypass press No. 28.
RY(n+3)2 BYPASS PRESS#29 NO 51 Bypass press No. 29.
RY(n+3)3 BYPASS PRESS#30 NO 52 Bypass press No. 30.
RY(n+3)4 BYPASS PRESS#31 NO 53 Bypass press No. 31.
RY(n+3)5 NO 54
RY(n+3)6 NO 55
RY(n+3)7 NO 56
RY(n+3)8 NO 57
RY(n+3)9 NO 58
RY(n+3)A NO 59
RY(n+3)B NO 60
RY(n+3)C NO 61
RY(n+3)D NO 62
RY(n+3)E NO 63
RY(n+3)F NO 64
