PREFACE
This manual should be used in conjunction with Instruction Bulletin 53MC5000, MICRO-DCI Proc-
ess Control Station, Revision 2 (formerly titled Instruction Bulletin 53MC5000, MICRO-DCI Modular
Controller, Revision 1). It is assumed the reader is familiar with the information presented in that
document to install and operate the 53MC5000 Process Control Station.
BOOK OVERVIEW
Section 1, Introduction - This section provides preliminary information to acquaint the user with
the product. Also provided is the 53MC5000 Process Control Station (PCS) Model Number Break-
down.
Section 2, Installation - This section provides mounting instructions for the RS-232/485 ITB, infor-
mation to cable an RS-232/485 ITB to the 53MC5000 Process Control Station, and information to
connect power to the RS-232/485 ITB.
Section 3, Product Description - This section provides general information about the product
functionality. More specific functional information is provided, as applicable, in each of the follow-
ing Sections 4 through 9.
Section 4, Allen-Bradley Mode - This section defines the datapoints that must be configured for
Allen-Bradley operating mode. It provides information to fabricate the RS-232/485 ITB-to-PLC ca-
ble and lists the Allen-Bradley commands used.
Section 5, OPTO 22 Mode - This section defines the datapoints that must be configured for
OPTO 22 operating mode. It provides information to fabricate the RS-232/485 ITB-to-OPTOMUX
station cable and lists the OPTOMUX commands used.
Section 6, MODBUS RTU Mode - This section defines the datapoints that must be configured for
MODBUS RTU master and slave operating modes. It provides information to fabricate the
RS-232/485 ITB-to-PLC cable and lists the MODBUS RTU commands used for both modes.
Section 7, Siemens S5 Mode - This section defines the datapoints that must be configured for Sie-
mens S5 operating mode. It provides information to fabricate the RS-232/485 ITB-to-PLC cable
and lists the Siemens S5 commands used.
Section 8, Koyo Mode - This section defines the datapoints that must be configured for Koyo oper-
ating mode. It provides information to fabricate the RS-232/485 ITB-to-PLC cable and lists the
Koyo commands used.
Section 9, Printer Interface - This section provides information to print-out the standard datalog
from the datalog display, or with FCS, F-CIM, or F-TRAN. It also provides two free format F-TRAN
datalog programs with print-out examples.
Section 10, Parts Replacement - This section provides the procedure to remove and replace the
DDI-A and DDI-B Auxiliary Processor Boards (APBs)
Appendix A, Base 2/8/10/16 Table - Binary/Octal/Decimal/Hexadecimal conversion table.
