Command Set CPU
%aannccff
(cr) is the terminating character, carriage return (0Dh).
Example command: %23000A40(cr)
response: !23(cr)
The ADAM-5000 system with address 23h is configured
to a baud rate of 115.2 Kbps and with checksum genera-
tion or validation.
The response indicates that the command was
received. Wait 7 seconds to let the new configuration
setting take effect before issuing a new command to the
system.
Note: All configuration parameters can be changed dynami-
cally, except checksum and baud rate parameters.
They can only be altered when the INIT* terminal is
grounded.
Figure 6-1 Baud rate codes
