Chapter 6
hexadecimal characters represent the channels’ status.
Note that the numbers of channels on the ADAM-5056
and ADAM-5055S/5060/5068/5069 differ.
- A 4-character hexadecimal value is used to set the
channels, from 15 thru 0, of the ADAM-5056.
- A 2-character hexadecimal value is used to set the
channels, from 5 thru 0, of the ADAM-5060. Bits 6 and 7
always default to 0 in the ADAM-5060.
- A 2 character hexadecimal value is used to set the
channels, from 7 thru 0, of the
ADAM-5055S/5068/5069.
Response >(cr) if the command was valid.
?aa(cr) if an invalid command has been issued.
There is no response if the module detects a syntax error
or communication error or if the specified address does
not exist.
> delimiter character indicating a valid command was
received.
? delimiter character indicating the command was
invalid.
aa (range 00-FF) represents the 2-character hexadecimal
address of an ADAM-5000 system that is responding.
(cr) is the terminating character, carriage return (0Dh)
Example command: #15S11201(cr)
response: >(cr)
An output bit with value 1 is sent to channel 2 of a
digital output module in slot 1 of the ADAM-5000
system at address 15h - either ADAM-5056 or ADAM-
5055S/5060/5068/5069. Channel 2 of the digital output
module is set to ON.
ADAM-5000 6-111
