Appendix
G
Appendix G ADAM-5000 I/O Modbus Mapping Table G- 7
410117~
410150
Reserved
410151~
410152
Slot0 Control & Status Flag
R/W
410153~
410154
Slot1 Control & Status Flag
R/W
410155~
410156
Slot2 Control & Status Flag
R/W
410157~
410158
Slot3 Control & Status Flag
R/W
410159~
410160
Slot4 Control & Status Flag
R/W
410161~
410162
Slot5 Control & Status Flag
R/W
Control & S
tatus Flag
410163~
410164
Slot6 Control & Status Flag
R/W
410165~
410166
Slot7 Control & Status Flag
R/W
410201~
410208
Slot0 Ch0~Ch15 Type Code
R
0x01 0x02
(0~10V, +/-5V)
410209~
410216
Slot1 Ch0~Ch15 Type Code
R
410217~
410224
Slot2 Ch0~Ch15 Type Code
R
410233~
410240
Slot4 Ch0~Ch15 Type Code
R
410241~
410248
Slot5 Ch0~Ch15 Type Code
R
410249~
410256
Slot6 Ch0~Ch15 Type Code
R
410257~
410264
Slot7 Ch0~Ch15 Type Code
R
