ADAM-5000 I/O Modbus Mapping Table
G-2 ADAM 5000 Series User’s Manual
The model list of ADAM-5000 I/O series support Modbus
protocol
G.1 The ADAM-5000 series main system’s DIP Switch
Setting:
z 5000/485:
„ #8 of DIP switch ON-> not fixed ٛ vaila address
„ #8 of DIP switch OFF-> fixed ٛ vaila address
z 5000/E: Same as 5000/485
z 5510(simu5000):
„ #5 of DIP swith ON->Modbus protocol
„ #5 of DIP swith OFF->Advantech protocol
„ Only fixed Modbus address ٛ vailable
(Note:
z The fixed Modbus address rule follows the
Adam-5000/TCP Modbus address rule
z The start address must be a number of series
number(1, 9, 17, …, n*8+1)
)
