Appendix
G
Appendix G ADAM-5000 I/O Modbus Mapping Table G- 5
G.3 Modbus Address Mapping
ADDR 4X
Item
Attribute
410001
Module Name 1
R
0x5485:5000/485
0x500E:5000/E
410002
Module Name 2
R
410003
Versoin 1
R
0xv2 0x72
410004
Versoin 2
R
0x00 0x00
410005
Slot0, 1 Module Name
R
0x18 0x10(5024, 5050)
410006
Slot2, 3 Module Name
R
0x01 (Ext.)
410007
Slot4, 5 Module Name
R
410008
Slot6, 7 Module Name
R
410009
Slot0, 1 Ext. Module Name
R
410010
Slot2, 3 Ext. Module Name
R
410011
Slot4, 5 Ext. Module Name
R
410012
Slot6, 7 Ext. Module Name
R
410013
Modbus Addr. Mode
R
0x0001:Fixed modbus address
0x0000: Flexible modbus
address
410014~
410020
Reserved
410021
Slot0 Start Addr.
R
40001
410022
Slot0 End Addr.
R
40008
410023
Slot1 Start Addr.
R
410024
Slot1 End Addr.
R
410025
Slot2 Start Addr.
R
410026
Slot2 End Addr.
R
410027
Slot3 Start Addr.
R
410028
Slot3 End Addr.
R
410029
Slot4 Start Addr.
R
