Appendix F
Figure F-15 : Noise Reduction Techniques
F.4 Check Point List
• Follow the single point grounding rule?
• Normal mode and common mode voltage?
• Separate the DC and AC ground?
• Reject the noise factor?
• The shield is connected suitable?
• The diameter of wire thick enough?
• How about the soldering of connection?
• The terminal screw tightly?
ADAM-5000 F-15
,
